Standard Accessories
- 10" Chuck Plate
- Spindle Sleeve
- 2 Dead Center
- Change Gear Set
- Tool Post Bolt Key
- Motor Pulley
| Range | Admit Between Center | Weight (Approx) |
| 4.5 feet | 450mm | 650kg. |
| 5ΒΌ feet | 725mm | 675kg. |
| 6 feet | 900mm | 750kg. |
| 7 feet | 1200mm | 800kg. |
| 8 feet | 1500mm | 900kg. |
Technical Specifications
| Height of Center | - | 215mm |
| Bed Width | - | 279mm |
| Swing over Bed | - | 425mm |
| Swing over Cross slide | - | 260mm |
| Movement of cross slide | - | 250mm |
| Swing in Gap | - | 620mm |
| Bed Type | - | 2V & 2 Flat |
| Drive V-Belt | - | B-48 |
| Spindle Bore | - | 50mm |
| Spindle Nose & Threadad | - | 75mm / 6TPI |
| Tail stock Spindle Dia/Taper | - | 50.8mm/MT-4 |
| Tail stock Spindle Travel | - | 150mm |
| Compound Dlide Travel | - | 150mm |
| Lead screw Diameter & pitch | - | 31.75mm/4TPI |
| Renge of Matric Threads | - | 0.5 to 7 |
| Renge of inch Threads | - | 4 to 48 TPI |
| Electric Motor 1440 RPM. | - | 2 HP/3 Phase |
